Sony VTC6A

Sony VTC6A For Sale 3000mAh

The Sony VTC6A for sale is a cylindrical 18650 cell with a flat top and 18mm x 65mm dimensions. It holds a maximum capacity of 3000mAh, performs with a continuous discharge rate of 15 Amps, and has a maximum discharge rate of 25 Amps. The Sony VTC6A battery suits vape mods with a max output power of 200W.

Sony US18650VTC6A Battery

The Sony US18650VTC6A battery has a high capacity, 25Amp self-discharge rate, and long cycle life. Its current solid charge and discharge capability has reached IEC standards. The Sony US18650VTC6A battery is unprotected and must be used in protective devices or by experienced users. It's safer chemistry, Li-Ion, requires a protection circuit and has a low risk of venting with flame or explosion.

Sony VTC6A Mooch Test

According to the Sony VTC6A Mooch test, the 20A VTC6A operates at the same temperature as the Sony VTC6 battery at 15A. Besides, the Sony VTC6A Mooch test estimate for the current VTC6A rating is 20A, up to 25A if the temperature is below 80C. Moreover, the Sony VTC6A Mooch test on 0.5A showed a minimum 2,892mAh rating and a typical 3,008mAh.

Battery Specs

• Continuous Discharge: 20A
• Max Discharge: 40A
• Capacity: 3000mAh
• Nominal Voltage: 3.6V
• Charge Voltage: 4.2V
• Self-Discharge:<2.0V
• Positive Side: Flat Top
• Chemistry: Li-Ion
• Lifespan: 500+ Cycles
• Protection: NOT PROTECTED*
• Charging Time: 4.2V/3.0A - 2.5 Hours
• Length: 65mm [+/- 0.2mm]
• Diameter: 18mm [+1.5mm /- 0.2mm]
• Weight: 47.5g [+/- 1.5g]

What's included

• 1 x Sony VTC6A 18650 Battery

UNPROTECTED BATTERY WARNING!

*Sony VTC6A battery is unprotected and intended for use in protected battery packs only and NOT individually or as a standalone product. To operate safely, it must have extra protection with a PCB [protection circuit board] or a BMS [battery management system], which isn't included.

By purchasing the Sony VTC6A battery, you agree to the following requirements:

• **Don't resell the battery
• **Don't throw the battery into a fire, nor heat the battery
• **For safety reasons, it's crucial that you do not disassemble or modify the battery.
• **Don't leave the battery in a place of high temperature [60C or more]
• **Don't use the battery at a high temperature [60C or more]
• **Don't expose the battery to water or moisture
• **Don't add strong shock, nor drop the battery
• **Don't solder leads directly to the battery body
• **Don't short the (+) and (-) terminals of the battery with a kind of metal
• **Never reverse-charge the battery.
• **For safety reasons, it's crucial not to puncture the battery with a nail or create a hole.
• **Don't put the battery into a microwave oven or high-pressure container

If the battery is damaged or shows visual defects, please stop using it immediately.
